Customized 50W 400MHz 500MHz 3G 4G Lora Digital Long Range RF
amplifier Jammer Module For Anti FPV
product Introduction
This is a 50W Lora digital jammer module specially designed for anti-FPV, UAV, and drones. drones,it takes advance lora digital technology which can operate
in same power RF longer distance with less consumption.
The dates of the anti-drone device test show that using the LORA digital module solution, the drone, which is in the air, can be interfered
with quickly. There is not using the Lora digital module anti-drone
device that takes more time than the Lora digital source module.
And the 50W LoRa digital jammer module outer shell is made of
aluminum material, which has waterproof and strongly heat-resistant
performance. 4 fixed screws around the module enhance the quality
of the product, matching 3 different electric wires when you
connect the testing machine to the specifications clearly.
Specification
| No. | Item | Data | Unit |
| 1 | Frequency | Customized | MHz |
| 2 | Test voltage | 24-28 | V |
| 3 | Current | 3.7 | A |
| 4 | Output | 50 | W |
| 5 | Gain | 47 | dB |
| 6 | Output stability | 1 | dB |
| 7 | Connector | SMA / Female |
| 8 | Output connector VSWR | ≤1.30 (No power and VNA test) |
| 9 | Power supply wire | Red+Black+Enable wire |
| 10 | Enable Control | High ON Low Off |
| 11 | Out shell Size | 137*43*16 | mm |
| 12 | Mount hole | 50*130 | mm |
| 13 | Weight | 290 | g |
| 14 | Work Temperature | -40~+65 | ℃ |
| 15 | Out shell material | Aluminum |
| 16 | Vibration need | Car load OK |
Features
Attention
* Power supply better carry about 28V 5.6A when itself 3.7A for its
stable work Heat dissipation measure is necessary including the
thermal glue, suitable-sizeheat sink and cooling fans
*Antenna or Load must be firstly connected before the power supply
is ON or it will be short wire
*Need read the Operation Manual first
*Need operate in 24-28V voltage
Packing &shipment
*Every product will test before shipment
*Takes carton plus foam packaging
*Have much shipment way can chosen
*Will covering film
Quality assurance
TX has own factory on the Shen Zhen of china
TX has advance spectrum equipment and promise 100% test
TX has professional engineer to deal with the problem
TX has a strong after-sales team
After service
*our company will perform the agreed responsibility and duty during
the warranty period
*Fast reply of Customer feedback and questions
* All product enjoy 1 year warranty and Life time maintenance
service
*User Instruction: we can offer online details photo illustration
and video;local instruction is also available but with extra cost
* Online technical support:our professional engineers will assist
customers with technical problems
