Outdoor computer connection long range UAV drone signal jammer blocker for oil depot

Description

This is a high power operate aluminum- made anti drone jammer device ,it takes radio frequency technology that can block drone signal around 1000-3000 meter .The jammer match 5 high gain antennas ,and the rf modules support customization so that users can freedom of choice.

Function

1. It can protect an area radius 1000-3000 meter away from UAV drone by stop remote control of wifi signal and GPS signal.

2. UAV status: no signal, no network, stop data and video transmission, stop action, land or return home

3. We can do 5.8G RF jammer module 40W or 50W, other module over 100W

Feature

1. Ultra high power 190W, combined with high gain directional antenna for each band

to shield radius 1000 to 3000 meter area (depends on real environment and signal strength)

2. 3 channel or More channel signal shielding IP64 level main control engine, or other customized frequency 433MHz, 868MHz, 912MHz, 916MHz, GPS/Glonass navigation signal,

3. Seperate fequency RF module and Single Switch control to exactly shield specific signal

also for customized frequency and easy maintainance

4. Efficient heat dissipation system: fast blow heat away to ensure long time operation

5. Optional monitoring software monitoring for client : can support PC operation, phone APP control,

drone detecting integrated system

6. VSWR protection: use power supply protection box, to ensure stable and safe power supply

7. Huawei latest high tech thunder protection box

8. Only influence downlink; No influence to base station

Main Engine Case

1. IP64 level die cast alluminum alloy design, Hinge lock protection for easy management and and anti-damage

2. N type connector(customized) to link with Antenna

3. Efficient heat dissipation system with built in fan and fin

4. Main switch to control the complete device work

5. Optional choice for directional or omni fiberglass antenna

6. Seperate module design, For single frequency control

7. LED indicates the working-on status

8. Over temperature and VSWR protection with power supply protection box

9. Please Ensure the anntenna is connected before turning power on

10. Slow set up circurity for long term reliabitly

Optional Frequency (10W, 20W,30W,40W, 50W, 100W; RF module also available )

CDMA/GSM850MHz:850-894MHz; 100W;
GSM900MHz:925-960MHz; 100W;
GSM/DCS1800MHz:1805-1880MHz; 100W;
3G/UMTS2100MHz:2110-2170MHz; 100W;
4GLte700MHz:790-826MHz; 100W;
4G/WiMAX2600MHz:2620-2690MHz; 100W;
WIFI2.4G:2400-2485MHz; 100W;
4G2500MHz:2500-2570MHz; 100W;
GPSL1:1570-1610MHz; 100W;
GPSL2:1200-1300MHz; 100W;
GPSL3:1380-1400MHz; 100W;
Wi-Fi5.8GHz:5725-5850MHz; 10W;
VHF:135-174MHz; 100W
UHF:400-470MHz; 100W
RC433MHz:433MHz; 100W
RC315MHz:315MHz; 100W
17.CDMA450MHz:450-470MHz; 100W;

Tests

Long time Aging test and Repeated Spectrum Analyzer tests to ensure products qualified

Installation Reference:

Different Solution:

Main Engine , Antenna ,Coxial, Connectors,etc.

Details Photo

Technical Data:

Antenna Data:

Company files

Shenzhen Texin Electronics Co., Ltd. is a professional manufacturer of anti-drone modules, anti-drone power amplifiers, anti-drone jammers and drone detectors. Our business in China started in 2008, and we first got involved in the education department exam jamming, conference room jamming and Chinese government prison jamming projects, designing and producing mobile phone WIFI signal jammers. From 2014, we also started overseas sales, because many foreign customers visited our factory and wanted to establish long-term cooperation with us. We decided to change our main products from mobile phone WIFI signal jammers to anti-drone jammers, not only because of the surge in inquiries for these products from our domestic and foreign customers, but also because our factory has a core team of engineers who can complete these anti-drone projects in a high-performance and cost-effective manner. From 2019 to 2024, our factory will have thousands of project experience in anti-drone solutions.

   Shenzhen Texin Electronics Co., Ltd is a professional signal jammer factory located in Shenzhen,China from 2014.

   Our main product is the RF jammer modules, drone signal jammer, Phone WIFI signal jammer, GPS signal jammer. The types include the large fixed type, desktop type, wall-mount type, handheld type, mini type, etc.

   These products are neccessary for air security or information security in places such as oil depot, chemical factory, mine field, border line petrol station, prison, conference room, examination room, etc.

   We can handld with customized projects with key know-how and enormous experience, for we have good cooperation with international customers over 80 countries such as USA, Russia, Europe, Middle-East,etc

Welcome to visit us at our factory !
