Brand Name : | TX TELSIG |
Model Number : | TX-A-NJB |
Certification : | SGS,ISO9001 |
Price : | Negotiation |
Payment Terms : | T/T,Paypal, Etc. |
Supply Ability : | 50,000pcs/month |
Delivery Time : | In 2 work day |
Phone signal antenna for Long distance high gain Omnidirectional 2G 3G 4G
TXtesig is an expert in designing and producing the signal jamming and wireless coverage
product.
TX-A-NJB Popular in Bluetooth, WIFI,Zigbee and WLAN embedded applications, the antenna
allows users a longer working range than a standard on board chip antenna which is offered on
many modules.
Specification
Operating temperature range | -20°C to 65°C |
Impedance | 50 ohm |
Gain | 3DBi |
VSWR | ≤1.6 |
Voltage and supply current | Passive |
Operating frequency | 800-900MHZ |
Polarization | Vertical |
Radiating element and wave | ¼ wave dipole |
Size | 180mm |
Connector | N |
Protection Rating | IP66 |
Mounting Way | Direct Mount |
![]() |
