    High Gain Two Way Radio Base Station Antenna 800 - 2600MHZ Frequency Optimized Size

    Ask Lasest Price
    Brand Name : TX TELSIG
    Model Number : TX-A-J2
    Certification : SGS,ISO9001
    Price : Negotiation
    Payment Terms : T/T,Paypal, Etc.
    Supply Ability : 200,000pcs/month
    Delivery Time : In 2 work day
    • Product Details
    • Company Profile

    High Gain Two Way Radio Base Station Antenna 800 - 2600MHZ Frequency Optimized Size

    High gain/Full day working/Optimized Size/Dual Polarization Base Station Antenna


    TX-P1 Frequency: 800-2600MHZ

    TXtelsig is an 10-year expert in signal jamming and wireless coverage product.


    High Gain Two Way Radio Base Station Antenna 800 - 2600MHZ Frequency Optimized Size


    1. Radome Seal

    The seal is made from high-molecular polymer silica gel that can form a seamless waterproof

    layer for terrible environment

    2. Radome

    The antenna shell is made from PVC material which is non flammable, very hard and excellent

    geometric stability.

    3. Heat-Resistant Circuit Board

    Made from rogers material covered with anthracene dye that is effective to prevent external disturbance

    and increase the antenna gain.

    4. Zinc Alloy Vibrator/ Radiation

    The vibrator is covered with tin plating which is effective to prevent deterioration and prolong life-span

    of antenna and reduce the loss and ensure the antenna gain.

    5. Multifunctional Adjustable Mounting kits

    Made from stainless steel material of removal hydrogen that is stable and durable. The mounting kits

    can be adjustable according to your specific situation in order to realize perfect coverage of signal.

    6. N-K connector

    Known as N-Female connector, made from fine overgilded copper which is effective to reduce signal

    loss and help the antenna work more efficient.


    High Gain Two Way Radio Base Station Antenna 800 - 2600MHZ Frequency Optimized Size


    Specification

    Electrical Specification
    Frequency Range800~2600MHZ
    Polarization±45°
    Gain2*18
    Half power beam width (°)H:65 V:7
    Front to back ration≥25
    Input Impedance (Ω)50
    VSWR≤1.5
    Isolation between ports≥28dB
    Cross polar ration≥15dB@0° ≥10dB@±-60°
    Sidelobe suppression fro first sidelobe above horizon15dB
    Max input power200
    Lightning ProtectionDC Ground
    Mechanical Specification
    Input Connector Type2-N female
    Size1120*175*80
    Packing Size1190*200*150
    Antenna Weight6.5kg
    Radome MaterialUPVC
    Radome ColorGray
    Mechanical Tilt (°)0~10
    Operation Temperature-40℃~60℃
    Rated Wind Velocity (m/s)60
    Mounting Hardware (mm)35-90


    High Gain Two Way Radio Base Station Antenna 800 - 2600MHZ Frequency Optimized Size


    Application

    1. DCS, PCS, 3G LTE system

    2. Wireless communication and data transmission system
